Protected against Anti-sabotage
MultiTransmitter will inform you instantly if the connected devices have been interrupted with power failure, disconnection of the signal cable, or tampering. Electricity loss at the site will not be a problem either — the backup battery can provide power to devices for up to 4 days. MultiTransmitter body itself is equipped with two tampers that respond to removal of the integration module from the mount and removal of the lid.
Instant connection loss detection with wired device (EOL)
Cavity in the body for a backup battery 7 A⋅h
2 tampers that detect dismounting and opening of the body
Instant connection loss detection with wired device (EOL)
Cavity in the body for a backup battery 7 A⋅h
2 tampers that detect dismounting and opening of the body
Tech specs
| Number of alarm/tamper zones | 18 |
|---|---|
| Supported detector contact types | NO, NC (without R), EOL (NC with R), EOL (NO with R) |
| Resistance of the EOL resistor | 1 kΩ to 7.5 kΩ |
| Alarm signals processing mode | Pulsed or bistable |
| Main power supply | 110–255 V, 50/60 Hz |
| Backup power | 12 V DC |
| Supported battery type | Battery with 4 or 7 A⋅h capacity (not included), dimensions 150 × 64 × 94 mm |
| Detector power supply | 12 V DC, up to 1 A for all detector power supply outputs |
| Protection against dismantling | Tamper |
| Radio signal frequency band | 866.0 – 866.6 MHz |
| Compatibility | Operates with all Ajax hubs, and range extenders |
| Maximum radio signal power | Up to 7.29 mW (25 mW limit) |
| Radio signal range | Up to 2,000 m in the line of sight |
| Operating temperature range | From -10°С to +40°С |
| Up to 75% | Available |
| Operating temperature range | From -25°С to +50°С |
| Permissible humidity | Up to 75% |
| Dimensions | 196 × 238 × 100 mm |
| Weight | 805 g |
| Warranty | Replacement and repair within 24 months of the date of sale. |
| Complete set | MultiTransmitter board Body Installation kit Power cable User Guide |
