Multilevel anti-sabotage protection
MotionCam Outdoor can not be unnoticeably disabled even if the system is disarmed. The detector is equipped with masking sensors reacting to hindering, covering and painting the lens.
It will take the hub less than a minute1 to detect the loss of communication with the detector and inform a central monitoring station and users about the problem. The fact that MotionCam Outdoor was dismantled will become known instantly.
Anti-masking
Notifications about detachment
Configurable detector ping interval
Anti-masking
Notifications about detachment
Configurable detector ping interval
Effective security in any weather
MotionCam Outdoor resists the heat up to +60°С and withstand the cold down to −25°С. And to protect the sensors of the anti-masking system from rain and snow, we included a special hood.
Efficiency in heat and cold
IP55 enclosure protection
Bundled hood to protect from rain and snow
Efficiency in heat and cold
IP55 enclosure protection
Bundled hood to protect from rain and snow
Tech specs
| Classification | Electro-optical radio channel security detector |
|---|---|
| Detector type | Wireless |
| Installation method | Indoors / outdoors |
| Recommended installation height | 0.8 – 1.3 m |
| Compatibility | Hub 2, Hub 2 Plus Not compatible with ReX radio signal range extender |
| Sensing element | 2 × PIR sensor |
| Pet immunity | Animals up to 80 cm tall |
| Motion detector’s viewing angle | Horizontal — 90° Vertical — 80° |
| Camera’s angle | Horizontal — 105° Vertical — 50° |
| TV distortion (EBU standard) | Barrel, –17% |
| Photo in case of alarm | Photo resolution: 320 × 176 pixels (by default) 640 × 352 pixels Shooting series up to 5 photos |
| Infrared light for shooting in the dark | Available |
| Sensitivity | Adjustable, 3 levels |
| Power supply | 4 × CR123A batteries |
| Battery life | Up to 3 years (up to 2.5 years if “Delay when entering” setting is activated) |
| Jeweller radio technology | Communication range with a hub — up to 1,700 m in an open space Two-way communication between hub and device Operating frequencies — 868.0–868.6 MHz3 Self-adjusting RF output power — up to 20 mW Block encryption with a dynamic key Detector polling period — 12–300 s Frequency hopping |
| Alarm delivery time | 0.15 s |
| Wings radio technology | Transmission of a series of photos Photo delivery time with a default settings: up to 9 seconds |
| Temperature sensor | Available |
| Operating temperature range | From –25°С to +60°С |
| Operating humidity | Up to 95% |
| Protection class | IP55 |
| Anti-sabotage | Anti-masking Protection against forgery Jamming detection Tamper-resistant |
| Remote configuration and testing | Available |
| CMS compatibility | CMS connectivity: Contact ID, SIA (DC-09) |
| Dimensions | 206 × 108 × 93 mm |
| Weight | 470 g |
| Warranty | Replacement and repair within 24 months of the date of sale. Batteries are not covered under warranty. |
| Complete set | DMotionCam Outdoor motion detector SmartBracket mounting panel Hood visor 4 × CR123A batteries (pre-installed) Installation kit User’s guide |
